Change to read:
Related compounds
Solution A, Solution B, Mobile phase, System suitability solution, and Chromatographic system
Proceed as directed in the Assay.
Standard solution
Dissolve accurately weighed quantities of
USP Lidocaine RS and
USP Prilocaine Hydrochloride RS in
Solution A, and dilute quantitatively, and stepwise if necessary, with
Solution A to obtain a solution having a known concentration of about 0.002 mg per mL of each compound. Immediately store this solution at or below 10

.
Test solution
Use the Assay preparation, prepared as directed in the Assay.
Chromatographic system (see Chromatography
621
)
Proceed as directed in the
Assay. Chromatograph the
System suitability solution, and record the peak responses as directed for
Procedure: the relative retention times are listed in
Table 1; and the resolution,
R, between prilocaine and prilocaine related compound B is not less than 1.4. Chromatograph the
Standard solution a minimum of six times, and record the peak responses as directed for
Procedure: the relative standard deviation for replicate injections is not more than 5.0%.
Procedure
Separately inject equal volumes (about 50 µL) of the
Standard solution and the
Test solution into the chromatograph, record the chromatograms, and measure the peak responses. Calculate the percentage of each related compound in the portion of the Cream taken by the formula:
100C(rU / rS)(V/W)(100/L)(1/F)(220.31/256.77)
in which
C is the individual concentration, in mg per mL, of either
USP Lidocaine RS or
USP Prilocaine Hydrochloride RS in the
Standard solution; rU is the individual peak response of the impurities obtained from the
Test solution; rS is the individual peak response for either lidocaine or prilocaine obtained from the
Standard solution; V is the volume, in mL, of the
Test solution; W is the weight, in mg, of the Cream taken to prepare the
Test solution; L is the individual label claim, in percent, for either lidocaine or prilocaine;
F is the relative response factor for each related compound as listed in
Table 1; and 220.31 and 256.77 are the molecular weights of prilocaine and prilocaine hydrochloride, respectively (these are used only for calculation involving prilocaine related compounds). The percentages of lidocaine related compounds and prilocaine related compounds are calculated using the concentration and peak response from
USP Lidocaine RS and
USP Prilocaine Hydrochloride RS, respectively. The designation of whether an impurity is a lidocaine related compound or prilocaine related compound is specified in
Table 1. The percentage of any individual unknown related compound is determined using the concentration and peak response from
USP Prilocaine Hydrochloride RS in the
Standard solution.
Table 1
Related Compound |
Relative Retention Timea |
Relative Response Factor (F) |
Limit |
o-Toluidine |
0.38 |
2.3 (P)b |
not more than 2.0% |
n-Chloroacetyl-2,6-xylidine |
0.54 |
1.0 (L)c |
not more than 0.1% |
2,6-Dimethylaniline |
0.67 |
3.3 (L)c |
not more than 0.1% |
(RB 30-Nov-2007) |
|
|
|
Prilocaine |
1.00 |
|
|
(RB 30-Nov-2007) |
|
|
|
2-Diethylaminoaceto-2,4-xylidine |
1.33 |
0.8 (L)c |
not more than 0.1% |
Lidocaine |
2.14 |
|
|
n-Dichloroacetyl-2,6-xylidine |
2.98 |
2.2 (L)c |
not more than 0.1% |
Any other individual related compounds |
|
1.0 (P)b |
not more than 0.2% |
Total related compounds, excluding
o-toluidine |
|
|
not more than 1.0% |
a
Relative to the prilocaine peak.
b
P designates a prilocaine related compound.
c
L designates a lidocaine related compound.
|
Assay
Solution A
Dissolve about 2.73 g of monobasic potassium phosphate in 630 mL of water, and adjust with 5 N sodium hydroxide to a pH of 7.20 ± 0.02. Dilute with acetonitrile to 1 L.
Solution B
Dissolve about 2.73 g of monobasic potassium phosphate in 900 mL of water, and adjust with 5 N sodium hydroxide to a pH of 7.20 ± 0.02. Dilute with acetonitrile to 1 L.
Mobile phase
Use variable mixtures of filtered and degassed
Solution A and
Solution B as directed for
Chromatographic system. Make adjustments if necessary (see
System Suitability under
Chromatography
621
).
Standard preparation
Dissolve accurately weighed quantities of
USP Lidocaine RS and
USP Prilocaine Hydrochloride RS in
Solution A, and dilute quantitatively, and stepwise if necessary, with
Solution A to obtain a solution having a known concentration of about 0.2 mg per mL of each compound. Immediately store this solution at or below 10

.
System suitability solution
Dissolve an accurately weighed quantity of
USP Prilocaine Related Compound B RS in the
Standard preparation, and dilute quantitatively, and stepwise if necessary, with the
Standard preparation, to obtain a solution having a known concentration of about 0.08 mg per mL of prilocaine related compound B.
Assay preparation
Transfer a portion of the Cream, equivalent to about 20 mg each of lidocaine and prilocaine, accurately weighed, to a 100-mL volumetric flask. Add 5 mL of 5 N sodium hydroxide to disperse the Cream, and mix. Add 5 mL of 5 N hydrochloric acid, and dilute with
Solution A to volume, and mix. Pass a portion through a nylon filter having a 0.2-µm or finer porosity, discarding the first 1 mL, and use the filtrate. Immediately store this solution at or below 10

.
Chromatographic system (see Chromatography
621
)
The liquid chromatograph is equipped with a 232-nm detector and a 4.6-mm × 10-cm column that contains 3-µm packing L1. The flow rate is about 1.5 mL per minute. The column temperature is maintained at 40

. The samples are maintained at or below 10

. The chromatograph is programmed as follows.
Time (minutes) |
Solution A
(%) |
Solution B
(%) |
Elution |
0 |
67 |
33 |
equilibration |
011.0 |
67 |
33 |
isocratic |
11.022.0 |
67®100 |
33®0 |
linear gradient |
22.032.0 |
100 |
0 |
isocratic |
Chromatograph the
System suitability solution, and record the peak responses as directed for
Procedure: the relative retention times are 1.00 for prilocaine, 1.09 for prilocaine related compound B, and 2.14 for lidocaine; and the resolution,
R, between prilocaine and prilocaine related compound B is not less than 1.4. Chromatograph the
Standard preparation a minimum of five times, and record the peak responses as directed for
Procedure: the column efficiency is not less than 5000 theoretical plates, based on the prilocaine peak; the tailing factor is not more than 1.5, based on the prilocaine peak; and the relative standard deviation for replicate injections is not more than 2.0%.
Procedure
Separately inject equal volumes (about 50 µL) of the
Standard preparation and the
Assay preparation into the chromatograph, record the chromatograms, and measure the responses for the lidocaine and prilocaine peaks. Calculate the percentage of the label claim of lidocaine (C
14H
22N
2O) and prilocaine (C
13H
20N
2O) in the portion of Cream taken by the formula:
100C(rU / rS)(V/W)(100/L)(220.31/256.77)
in which
C is the individual concentration, in mg per mL, of either
USP Lidocaine RS or
USP Prilocaine Hydrochloride RS in the
Standard preparation; rU and
rS are either the individual peak responses of lidocaine or prilocaine obtained from the
Assay preparation and the
Standard preparation, respectively;
V is the volume, in mL, of the
Assay preparation; W is the weight, in mg, of the Cream taken to prepare the
Assay preparation; L is the individual label claim, in percent, for either lidocaine or prilocaine; and 220.31 and 256.77 are the molecular weights of prilocaine and prilocaine hydrochloride, respectively (these are used only for calculating the percentage of prilocaine in the Cream).
